Application of ATC cnc router with gang drilling :
Woodworking industry: wave plate, wood cabinet, cupboard door, fine pattern’s engraving, carving of the antique furniture,craft wood door, paint-free door, craft etc.
Advertising industry: advertising signs& label making, engraving of Acrylic, crystal words’ processing, plastic molding’s making, etc.
Crafts& gifts: toys, and processing of copper, aluminum, plastic, double-color board, marble.
Others: decorations, plastic light box, molds, wooden architechts’molds, product identification industry,carpentry furniture industry, teaching, enterprise and public
institution, etc.
- Size: 0
- Place of Origin: JINAN
- Brand Name: philicam multitech
- Model Number: LF1230
- Weight: 0.000 kg
1 | Model | ITM1325C |
2 | X,YWorking Area | 1300x2500mm |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.01/300mm |
4 | X,Y,Z Repositioning Accuracy | ±0.01mm |
5 | Table Surface | Vacuum |
6 | Frame | Welded machine structure |
7 | X, Y Structure | Gear and rack transmission, Taiwan HIWIN Linear Rail |
8 | Z Structure | Taiwan TBI Ball Screw, Taiwan HIWIN Linear Rail |
9 | Certificate | CE |
10 | Max. Rapid Travel Rate | 90000mm/min |
11 | Max. Working Speed | 60000mm/min |
12 | Spindle Power | 9KW HSD air cooling spindle from Italy |
13 | Spindle Speed | 0-18000RPM |
14 | Drive Motors | Japan YASAKAWA/Taiwan DELTA |
15 | Working Voltage | AC380V/50/60Hz,3PH (Option: 220V) |
16 | Command Language | G Code, PLT |
17 | Operating System | Tawain SYNTEC |
18 | Computer Interface | CF card interface |
20 | Warranty | 1 year |
21 | Inverter | Taiwan DELTA |
22 | Software Compatibility | Type 3 /Artcam |
